Specification
| AP Type | Wi-Fi 5 Ceiling AP (Cloud AP) |
|
| Model | XAP-5520-L | |
| Capability | Wi-Fi Protocol | 802.11ac Wave2/ac/a/b/g/n |
| Radio | 2.4GHz 5GHz（5.1G+5.8G） |
|
| Special Stream | 2+2 | |
| Wireless Soeed | 2.4G：300Mbps 5G：867Mbps |
|
| Maxmum Power | 2.4G：20dBm 5G：20dBm |
|
| Maximum Connected Devices | 256 | |
| Recommended Concurrent User | 30-40 | |
| Coverage Distance (Radius) | 10-15 Meters | |
| ESSID Quantity | 32 | |
| Antenna Type | Built-in Antenna | |
| interfaces | interfaces | 1*10/100/1000Mbps |
| Other ports | 1*USB Port | |
| Console port | 1 x RJ45 Console | |
| Power supply | Power supply | PoE Power power adapter |
| Power Supply Standard | 802.3af 12V/2A DC |
|
| power consumption（W） | ＜13 | |
| Hardware Specs | L*W*H(mm) | 196 *196 *45 |
| IP protection degreen | IP41 | |
| Weight(kg) | 0.5 | |
| Working environment | Operating Temperature | -10~50℃ |
| Operating Humidity | 5~95%RH | |
