Networking
Ruijie VG-SFP-LR-SM1310
Features
- • 25G Next-Gen Performance: Offers a massive bandwidth leap over standard 10G SFP+ modules while utilizing the exact same physical footprint size.
- • Digital Optical Monitoring (DOM/DDM): Outfitted with advanced telemetry diagnostics. Network administrators can track internal operating voltages, temperatures, laser bias currents, and transmit/receive optical power directly via the switch CLI.
- • Long-Range Efficiency: Capable of sending clear data streams across 10 km without the need for additional inline amplification over standard single-mode trunk cables.
- • Enterprise Hardware Longevity: Fully hot-pluggable, Class 1 Laser safety compliant, and RoHS environmentally approved. It can be swapped into a live port without impacting surrounding hardware systems or taking down adjacent active loops.
Specifications
- • Data Rate
- Up to 25 Gbps
- • Fiber Type
- Single-Mode Fiber (SMF)
- • Wavelength
- 1310 nm
- • Form Factor
- SFP28
- • Connector Type
- Duplex LC
- • Maximum Distance
- Up to 10 kilometers (10 km)
- • Power Consumption
- ≤ 1.5 W
- • Operating Temperature
- 0°C to 70°C (Commercial Grade)
- • Ethernet Standard Compliance
- 25GBASE-LR
