Ruijie RG-CS86-20XS4VS2QXS-D
Features
- Ruijie RG-CS86 Series Core Features Overview
- To give you a quick baseline of the RG-CS86 Series architecture, every switch in this lineup shares these high-end capabilities:
- • VSU Virtualization (Stacking): Combines physical units into a single logical switch for simplified management and sub-200ms link failovers.
- • Full Layer 3 Dynamic Routing: Line-rate IPv4/IPv6 dual-stack processing using enterprise protocols like OSPF, BGP, and IS-IS.
- • Dual-Chip Boot Redundancy: Hardware-level 1+1 Flash backup to protect against system crashes during firmware upgrades.
- • Advanced Protection (CPP & NFPP): Native security policies that shield the switch CPU from DDoS traffic and isolate network scanning or ARP spoofing attacks.
- • Lifetime Free Ruijie Cloud: Supports zero-touch deployment, live topology mapping, and remote monitoring via web or mobile app.
Specifications
- • ARP Entries
- 16,000 entries.
- • MAC Addresses
- 32,768 entries.
- • Boot Redundancy
- Hardware-enforced 1+1 BootROM redundancy utilizing dual storage chips to protect the device during system updates.
- • Database Tables
- • System Hardware
- 1.25 GHz processor, equipped with 1 GB SDRAM and 1 GB Flash memory.
- • IP Routing Routes
- Supports up to 16,000 IPv4 unicast routes and 16,000 IPv6 unicast routes.
- • System Management
- 1 x RJ45 Console port, 1 x dedicated RJ45 MGMT port, and 1 x USB configuration port.
- • Cooling Redundancy
- 2 x modular fan slots supporting 1+1 fan redundancy, with two M1SFAN I-F variable-speed fan modules pre-installed by default.
- • Security Shielding
- Native CPU Protection Policy (CPP) and Network Foundation Protection Policy (NFPP) shield the internal engine from DDoS attacks, network scans, and ARP spoofing storms.
- • Switching Capacity
- 760 Gbps line-rate multi-layer switching.
- • VSU Virtualization
- Supports Virtual Switch Unit technology to stack up to 2 physical switches into a single logical unit. This unifies management via a single IP/CLI and delivers sub-200ms failovers if a member link goes offline.
- • Fixed Fiber SFP+ Ports
- 20 x 1GE/2.5GE/10GE SFP+ ports providing multi-gigabit downward and cross-rack aggregation.
- • Packet Forwarding Rate
- 570 Mpps.
- • High-Speed Uplink Slots
- 4 x 10GE/25GE SFP28 ports (Note: All SFP28 slots must run at the same synchronized speed—either 10G or 25G).
- • Power Module Redundancy
- Features 2 x modular slots supporting 1+1 power redundancy. Uses the hot-swappable Ruijie RG-PA150IB-F 150W AC power module (chassis requires at least one).
- • Advanced Layer 3 Routing
- Line-rate processing for an IPv4/IPv6 dual-stack, running dynamic routing protocols such as OSPFv2/v3, BGP4/4+, RIP/RIPng, and IS-ISv4/v6.
- • Central Cloud Management
- Offers lifetime-free telemetry orchestration through the Ruijie Cloud console or mobile app for zero-touch provisioning and topology mapping, alongside SNMPv3, SSH, and a standard CLI
- • Ultra-High-Speed Backbone Slots
- 2 x 40GE QSFP+ uplink ports for bulk traffic transport directly to the network core.
