Ruijie Reyee RG-RAP1200(P)-MNT

Specifications

• Product Type

Dedicated Universal Mounting Bracket / Rack

• Mounting Design

Low-profile adapter plate layout equipped with multiple pre-drilled anchor holes for global junction box variations.

• Compatible Models

Ruijie Reyee RG-RAP1200 Series (such as RG-RAP1200(P) and RG-RAP1200(F))

• Locking Mechanism

Secure mechanical slide/click-lock design. It includes two integrated M4 × 5 retaining nuts acting as rigid fastening connection points for anchoring the main AP hardware securely to the plate.

• Precision Spacing

Features standard 60.3 mm lower spacing, 63 mm side spacing, and integrated multi-alignment configurations (46 mm, 50 mm, and 83.5 mm).

• Thermal Management

Passive structural outline engineered specifically to respect the airflow paths of the AP, ensuring no hindrance to internal heat dissipation.

• Material Composition

Flame-retardant, high-strength ABS plastic / Polycarbonate (PC)

• Application Environment

Indoor use only

• Dimensions (L × W × H)

126 mm × 86 mm × 5 mm (Some regions specify a 4 mm profile thickness)

• Surface Treatment & Color

Ruijie Warm White W-1 (fine-grained finish to precisely match the AP's aesthetics)
