Ruijie Reyee RG-NIS-PA240-54

Features

• Electrical Performance & Output
• • Total Output Power: 240W continuous rated output.
• • Rated Output Voltage: 54V DC.
• • Output Voltage Adjustability: Regulated adjustment range between 52.38 VDC and 55.62 VDC.
• • Max Output Current: 4.4 A constant current capacity.
• • Energy Efficiency: Highly efficient industrial design, operating with optimal thermal conversion to minimize waste.
• Input Architecture
• • Rated Input Voltage: Universal 100V AC to 240V AC (50/60 Hz).
• • Absolute Input Tolerance Range: Operational window spanning 90V AC to 264V AC (47 Hz to 63 Hz).
• • Max Input Current: 3.5 A maximum.
• • Status Indicator: Front-facing DC OK LED for immediate diagnostic status checks.
• Industrial Safeguards & Protection
• • Self-Recovery Circuitry: Includes active built-in protection against:
• • Short-circuiting
• • Over-current / Overload
• • Over-voltage
• • Over-temperature / Overheating
• • Surge Immunity: Common Mode: 4 kV / Differential Mode: 2 kV.
• • Electrostatic Discharge (ESD): 8 kV atmospheric (air) discharge / 6 kV contact discharge.
• • Ground Leakage Current: Highly secure layout limited to ≤ 0.5 mA.
• Mechanical & Environmental Specifications
• • Chassis Composition: Heavy-duty, rigid metallic enclosure.
• • Cooling System: Fully passive, fanless structural cooling. It operates silently and prevents internal dust/particle accumulation.
• • Heat Dissipation Rate: 820.8 BTU/hr at 220V/50Hz.
• • Mounting Configuration: Integrated native 35mm standard DIN-rail mount for clean integration into control cabinets.
• • Operating Temperatures: Rugged deployment rating from -40°C to +70°C (-40°F to 158°F).
• • Humidity Limits: 5% to 95% Relative Humidity (RH), non-condensing.
• • Mean Time Between Failures (MTBF): Heavy industrial lifespan rating exceeding 150,000 operational hours.
• • Dimensions & Weight: 52 mm x 110 mm x 125 mm; approximately 0.75 kg.
• • Warranty: 3-year manufacturer's warranty.
