Ruijie Reyee RG-NBS3200-24SFP/8GT4XS

Features

• Key Specifications
• • Product Type: Gigabit Layer 2+ Cloud-Managed Fiber Aggregation Switch (Non-PoE)
• • Dedicated Fiber Ports: 24 × 1GE SFP optical slots (100/1000 Mbps)
• • Combo Ports: 8 × Gigabit Combo ports (each can alternate between a 10/100/1000BASE-T RJ45 copper or a 1GE SFP optical module)
• • Uplink Ports: 4 × 10GE SFP+ optical slots
• • Switching Capacity: 128 Gbps
• • Packet Forwarding Rate: 96 Mpps (95.23 Mpps)
• • Packet Buffer: 12 Mbit
• • MAC Address Table: 16,000 entries
• • Maximum VLANs: 4,094
• • Cooling: 2 × fixed cooling fans providing left-to-rear forced airflow
• • Surge Protection: ±6 kV common mode on service ports; ±6 kV common and differential mode on the power connection
• Power & Environment
• • Power Input: Rated 100V AC to 240V AC, 50/60 Hz, Max 2A (Internal power supply)
• • Power Consumption: Max ≤ 42W (Absolute max 41.8W)
• • Operating Temperature: 0°C to 50°C (32°F to 122°F)
• • Operating Humidity: 10% to 90% RH (non-condensing)
• • Operating Altitude: –500 m to +5,000 m (–1,640 ft to +16,404 ft)
• Physical Dimensions & Design
• • Chassis: Standard 19-inch 1U rack-mountable industrial metal enclosure
• • Dimensions (W x D x H): 440 mm × 267.5 mm × 43.6 mm
• • Weight: 3.35 kg (7.39 lbs) net weight
• • MTBF (Mean Time Between Failures): 400,000 hours
• Management & Software Features
• • Cloud Control: Free lifetime deployment monitoring and remote configuration via the Ruijie Cloud web portal and Reyee Mobile App.
• • Layer 2+ Capabilities: Supports Layer 3 static routing for baseline IPv4 and IPv6 localized traffic segmentation.
• • Enterprise Security: Built-in CPU Protect Policy (CPP), Access Control Lists (ACLs), DHCP Snooping, 802.1X authentication, and IP Source Guard.
• • Optimization & Loop Fixes: Link Aggregation (LACP), IGMP Snooping for video multicasting, and RLDP loop prevention.
• • CCTV Intelligence: Includes smart IP camera automated detection to streamline surveillance layout topology charts within your cloud map.
