Ruijie Reyee RG-NBS3200-24GT4XS

Features

• Key Specifications
• • Product Type: Gigabit Layer 2+ Cloud-Managed Switch (Non-PoE)
• • Downlink Ports: 24 × 10/100/1000BASE-T RJ45 ports
• • Uplink Ports: 4 × 10GE SFP+ optical slots
• • PoE Capabilities: Non-PoE (For the power-delivery version, see the -P variant)
• • Switching Capacity: 128 Gbps
• • Packet Forwarding Rate: 95.24 Mpps (96 Mpps)
• • Packet Buffer: 12 Mbit
• • MAC Address Table: 16,000 entries
• • Maximum VLANs: 4,094
• • Memory / Flash: 512MB RAM, 256MB Flash
• • Cooling: 1 × built-in fixed fan with air cooling (left-to-rear airflow)
• • Surge Protection: ±6 kV common mode for service ports; ±6 kV common and differential mode for the power connector
• Power & Environment
• • Power Input: Rated 100V AC to 240V AC, 50/60 Hz (Fixed internal power supply)
• • Operating Temperature: 0°C to 50°C (32°F to 122°F)
• • Operating Humidity: 10% to 90% RH (non-condensing)
• • Operating Altitude: 0 to 5,000 meters (0 to 16,404 ft)
• Physical Dimensions & Design
• • Chassis: Standard 19-inch 1U rack-mountable metal case
• • Dimensions (W x D x H): 440 mm × 207.5 mm × 43.6 mm
• • Weight: 2.9 kg (6.39 lbs) without packaging
• • MTBF (Mean Time Between Failures): > 200,000 hours
• Management & Software Features
• • Cloud Management: Full, lifetime free remote cloud control using the Ruijie Cloud web portal and Reyee Mobile App.
• • Layer 2+ Capabilities: Supports management interface VLAN (SVI). (Note: It does not support heavy Layer 3 static routing).
• • Network Features: RLDP loop prevention, Link Aggregation Control Protocol (LACP up to 8 groups / 8 ports per group), Voice VLAN, IGMP Snooping, DHCP Snooping, and integrated CPP (CPU Protect Policy).
• • CCTV Enhancement: Automated IP Camera Recognition for targeted video streaming optimization and easy smart surveillance mapping.
