Ruijie Reyee RG-NBS3100-24GT4SFP-P-V2

Features

• Key Specifications
• • Switch Type: Layer 2 Smart Cloud-Managed Switch
• • Total Ports: 28 ports
• • Ethernet Layout: 24 x 10/100/1000BASE-T Gigabit RJ45 PoE/PoE+ ports
• • Fiber Uplink Slots: 4 x independent 1GE SFP optical slots (no port sharing)
• • PoE Output Capacity: 370W total continuous power budget (delivering up to 30W max per port under IEEE 802.3af/at standards)
• • PoE Power Pin Mapping: 1–2 (+), 3–6 (–)
• • Switching Capacity: 56 Gbps
• • Packet Forwarding Rate: 41.66 Mpps (with some datasheets showing a burst capacity up to 78 Mpps)
• • MAC Address Table: 8,000 entries
• Network Optimization & Software Intelligence
• • Management Integration: Free lifetime remote network management via the Ruijie Cloud Portal and mobile application, alongside standard Web GUI, SNMP, and local CLI controls.
• • Advanced Layer 2 Infrastructure: Supports 802.1Q tagging across up to 4,094 active VLANs, automatic Voice VLAN segregation, and IGMP Snooping (v1/v2/v3) for clean multicast video streaming.
• • Redundancy & Loop Mitigation: Fully supports STP/RSTP/MSTP protocols and ERPS (Ethernet Ring Protection Switching) for configuring self-healing fiber ring loops.
• • Automated Surveillance Diagnostics: Features native IP Camera Auto-Recognition and an intelligent PoE Watchdog engine that runs an isolated power reboot on unresponsive cameras.
• • Traffic Regulation: Features Access Control Lists (ACL up to 1,200 rules) and Quality of Service (QoS) bandwidth shaping.
• Physical, Environmental & Electrical Specs
• • Chassis Layout: 19-inch 1U standard metal rackmount frame.
• • Dimensions & Weight: 440 mm x 215 mm x 44 mm; Net Weight: 3.5 kg. (Note: The V2 chassis depth is trimmed down to 215 mm compared to the older V1 depth of 293 mm, offering a cleaner fit in shallow wall cabinets).
• • Thermal System: Equipped with an active cooling fan configured for Left-to-Right directional airflow.
• • Physical DIP Toggle Button: A physical front panel button alternates the port LED modes instantly between tracking regular link traffic and evaluating active PoE power utilization.
• • Surge Immunity: Built-in heavy-duty 6 kV protection against lightning strikes across both service copper lines and the main AC terminal.
• • Power Supply Module: Fixed interior power board supporting standard 100V to 240V AC (50/60 Hz).
• • Climate Operations: Built to withstand temperature thresholds ranging from 0°C to +50°C (32°F to 122°F).
• • Hardware Warranty: Backed by an extensive 5-year manufacturer's warranty.
