Ruijie Reyee RG-ES220GS-P-V2

Features

• Hardware Specifications
• • Model: RG-ES220GS-P-V2
• • Product Category: Layer 2 Smart Cloud-Managed Switch
• • Downlink / PoE Ports: 16 x 10/100/1000BASE-T (PoE/PoE+) RJ45 ports (IEEE 802.3af/at)
• • Uplink Ports: 2 x 10/100/1000BASE-T RJ45 ports + 2 x 1GE SFP optical slots
• • Total Ports: 18 x Gigabit RJ45 ports + 2 x Gigabit SFP ports (20 ports total)
• • PoE Power Budget: 250 W (Max 30W per individual port)
• • Switching Capacity: 40 Gbps
• • Forwarding Rate: 29.76 Mpps
• • MAC Address Table: 8,000 entries
• • VLAN Support: Up to 16 active VLANs (IEEE 802.1Q)
• • Cooling Design: 1 x Built-in fan with automatic speed control (stops running below 25°C)
• • Surge Protection: ±4 kV (common mode on service ports) / ±6 kV (power connector)
• • Chassis & Form Factor: Durable metal 19-inch 1U standard configuration (supports desktop or rack-mount)
• • Dimensions (W x D x H): 300 mm × 223 mm × 43.6 mm
• • Net Weight: 2.12 kg
• • Power Supply: Integrated internal AC power supply (100–240 V AC input, 4.5 A)
• • Power Consumption: Maximum 15W–20W (idle/no PoE load) up to 265W (full PoE load)
• • Warranty: 3-Year Manufacturer Warranty
• Key Features
• • ERPS Ring Protocol Support: The defining V2 feature addition. ERPS (Ethernet Ring Protection Switching) links the two built-in SFP fiber slots together to build a multi-switch recovery ring. If a fiber link breaks, the data traffic reroutes instantly to secure maximum redundancy.
• • IP Camera Capacity: Engineered specifically for massive surveillance matrices, it handles up to 80 x 2MP H.265 cameras or up to 40 x 4MP H.265 cameras smoothly without stuttering or video packet loss.
• • Perpetual PoE & Watchdog: Features smart CCTV backup loops. The power lines feed connected infrastructure non-stop during soft updates, and the switch automatically power-cycles any frozen IP camera port it tracks.
• • Lifetime-Free Cloud Management: Complete setup via Self-Organizing Network (SON) deployment, real-time port power graphs, data tracking, and dynamic visual topologies on the Ruijie Cloud App/Portal.
• • Front DIP Toggle: A dedicated front layout switch changes the 16 port indicator lights on the fly from Mode 1 (Network traffic status links) to Mode 2 (Real-time active PoE deployment thresholds).
