Ruijie Reyee RG-ES208GC-V2

Features

• Hardware Specs & Switching Performance
• • Total Ports: 8 × 10/100/1000BASE-T Gigabit RJ45 Ports (All copper ports, no SFP slots).
• • Switching Capacity: 16 Gbps of total backplane switching bandwidth.
• • Packet Forwarding Rate: 11.90 Mpps.
• • MAC Address Table: 4,000 entries.
• • PoE Capability: None (Data-only switch powered via an external power adapter).
• CCTV Optimization & Smart Features
• • Smart IP Camera Recognition: Instantly auto-discovers connected IP cameras and Network Video Recorders (NVRs) across the local network. It maps out your network topology visually right inside the app.
• • Automatic Loop Prevention: It automatically monitors for broadcast loops (e.g., a cable accidentally plugged back into the same switch) and blocks the specific loop port to keep the network stable.
• • Network Segmentation: Supports up to 32 concurrent VLANs (IEEE 802.1Q) to safely isolate cameras, guests, or employee networks.
• • Management Options: Fully configurable via local web interface or remotely through the Ruijie Cloud App & Web Portal for free.
• Physical, Ruggedness & Electrical
• • Heavy-Duty Surge Protection: Features built-in 6 kV surge protection on all Ethernet ports to defend against voltage spikes and lightning strikes.
• • Chassis & Cooling: Premium matte-black metal desktop chassis utilizing a fanless, noiseless design for entirely silent operation anywhere.
• • Power Consumption: Exceptionally eco-friendly, drawing a maximum of just 4.5 Watts under full traffic.
• • Power Supply: External DC 9V / 0.6A power adapter.
• • Dimensions (W x D x H): 160 mm × 75 mm × 24 mm.
• • Weight: 0.35 kg.
