Ruijie Reyee RG-ES207GS-PI-OD

Features

• Key Specifications
• • Switch Type: Layer 2 Smart Outdoor Cloud-Managed Switch
• • Total Ports: 7 ports total (5 RJ45 copper ports + 2 SFP optical uplink ports)
• • Ethernet Port Layout:
• • Ports 1–4: 10/100/1000BASE-T PoE Out ports (supporting IEEE 802.3af/at PoE/PoE+)
• • Port 5: 10/100/1000BASE-T PoE In / non-PoE Uplink copper port
• • Optical Uplink Ports: 2 x 1GE SFP optical ports (optimized for long-distance multi-node fiber rings)
• • Switching Capacity: 14 Gbps
• • Packet Forwarding Rate: 10.42 Mpps
• Dual Power Options & Dynamic PoE Budget
• Unlike traditional switches, its total PoE power output capability scales dynamically based on your chosen upstream power source:
• • Powered via 90W PoE++ Input (IEEE 802.3bt): Delivers a 60W total PoE output budget to downstream cameras.
• • Powered via 60W PoE++ Input (IEEE 802.3bt): Delivers a 40W total PoE output budget.
• • Powered via 30W PoE+ Input (IEEE 802.3at): Delivers a 19W total PoE output budget.
• • Powered via 15.4W PoE Input (IEEE 802.3af): Delivers a 6W total PoE output budget.
• • Powered via Direct 12V DC Input: Designed to connect directly to solar controllers or batteries (12V DC, 0.5A input), providing local system operation.
• • Note: Only one power input method (PoE In vs. DC Input) can be active at a time, and a grounding wire must always be attached.
• Software & Resilience Features
• • Management Platform: Free lifetime cloud management through the Ruijie Cloud ecosystem, eWeb interface, and Reyee mobile application.
• • ERPS Fiber Ring Protocol: Supports Ethernet Ring Protection Switching (ERPS) to engineer highly resilient, self-healing network ring paths for expansive perimeter deployments.
• • Smart PoE Watchdog: Monitors connected cameras around the clock and automatically power-cycles the specific PoE port if a device locks up.
• • Smart CCTV Recognition: Automatically discovers and categorizes IP cameras and Network Video Recorders (NVRs) to display live interactive topology maps.
• Physical & Weatherproofing Details
• • Chassis Rating: Sealed plastic housing with an IP65 weatherproof rating (completely dustproof and resistant to driving rain).
• • Cooling Architecture: Passive, fanless design relying on natural cooling.
• • Surge & ESD Protection: Built to handle open environments with ±8 kV PoE surge protection and 8 kV Air / 6 kV Contact ESD shielding.
• • Operating Temperatures: Heavy industrial grade rating from -30°C to +65°C (-22°F to 149°F).
• • Dimensions & Weight: 258 mm x 200 mm x 62.8 mm; 0.95 kg (2.09 lbs).
• • Mounting Type: Built-in configurations supporting immediate Wall or Pole mounting via clamps.
