Ruijie Reyee RG-ES110FG-P

Features

• Hardware & Interface Specifications
• • Total Ports: 10 Ports
• • Downlink: 8 × 10/100BASE-T RJ45 ports supporting PoE/PoE+ (IEEE 802.3af/at)
• • Uplink: 2 × 10/100/1000BASE-T RJ45 ports (Gigabit Ethernet)
• • Max PoE per Port: 30 W
• • PoE Budget: 110 W total power budget
• • Surge Protection: 4 kV common mode for service ports
• • Physical DIP Switch Modes:
• • Default Mode: Standard operational layout; all ports communicate normally with full flow control active.
• • Extend Mode: Reduces the link speed of PoE ports 1–8 down to 10 Mbps but extends the stable cable transmission range up to 250 meters.
• • Isolation Mode: Isolates downlink ports 1 through 8 from one another, allowing them to only communicate with the Gigabit uplink ports 9 and 10 to eliminate broadcast storms.
• Performance & System Architecture
• • Switching Capacity: 5.6 Gbps
• • Forwarding Rate: 4.17 Mpps
• • MAC Address Table: Up to 8,000 entries (8K)
• • Flash Memory: 2 MB
• • Smart Maintenance: Integrated hardware PoE Watchdog (automatically detects frozen powered devices and power-cycles the individual port to revive them).
• Power & Environment
• • Power Supply: Internal power design supporting AC input from 100V AC to 240V AC, 50/60 Hz
• • Power Consumption: ≤ 10 W (without PoE load) / up to 110 W (under full PoE load)
• • Cooling: Fanless, completely silent passive cooling through its metal housing
• • Operating Temperature: 0 °C to 45 °C (32 °F to 113 °F)
• • Operating Humidity: 10% to 90% RH (non-condensing)
• Physical Characteristics
• • Casing Material: High-strength Metal / Steel casing
• • Dimensions (W × D × H): 166 mm × 132.6 mm × 43 mm (6.54 in. × 5.22 in. × 1.69 in.)
• • Weight: 0.97 kg (Device only)
• • Mounting: Desktop or wall-mounted installation
• Cloud Visibility
• • Ruijie Cloud Integration: Operates completely plug-and-play with zero local configuration. It maintains Ruijie Cloud topology visibility, self-mapping onto your remote management layout when at least one managed Ruijie switch or gateway is active elsewhere on the local network.
• • Warranty: 3-year warranty
