Ruijie Reyee RG-ES105GD

Features

• Hardware & Interface Specifications
• • Ports: 5 × 10/100/1000BASE-T RJ45 ports (Gigabit Ethernet)
• • PoE Support: Non-PoE
• • Operating Modes: Half-duplex, full-duplex, and Auto-Negotiation
• • Supported Technologies: Auto-MDI/MDIX
• • Surge Protection: 6 kV for service ports (offering superior lightning/static shielding compared to the 4 kV rating on the plastic equivalents)
• Performance & System Architecture
• • Switching Capacity: 10 Gbps
• • Forwarding Rate: 7.44 Mpps
• • MAC Address Table: Up to 2,000 entries (2K)
• • Flash Memory: 1 MB
• • Switching Method: Store-and-Forward
• Power & Environment
• • Power Supply: External 5V DC / 1A power adapter
• • Max Power Consumption: ≤ 5 W
• • Cooling: Fanless, completely silent operation (the high-strength metal shell acts as a passive heat sink)
• • Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
• • Operating Humidity: 10% to 90% RH (non-condensing)
• • MTBF: > 200,000 hours
• Physical Characteristics
• • Casing Material: High-strength Metal
• • Dimensions (W × D × H): 119 mm × 62 mm × 24 mm (or 119 mm × 75 mm × 24 mm depending on the manufacturing batch hardware revision)
• • Weight: 250 g (0.55 lbs) without packaging
• • Mounting: Desktop or wall-mounted
• Cloud Visibility & Management
• • Ruijie Cloud Integration: It functions as a zero-configuration plug-and-play switch. However, it retains Ruijie Cloud topology visibility. If there is at least one managed Ruijie gateway or switch acting as the master controller on your local network, the RG-ES105GD will automatically map itself onto your visual network management dashboard.
• • Warranty: 3-year warranty
