Ruijie Reyee RG-EG105GW(T)

Features

• Hardware & Wireless Specifications
• • Wi-Fi Standard: Wi-Fi 5 (802.11ac Wave 2)
• • Wireless Speed: Combined dual-band speed of 1267 Mbps (400 Mbps on 2.4 GHz + 867 Mbps on 5 GHz)
• • Antennas: Built-in Omni-directional antennas. It has no visible external antennas, making it look very clean and minimalistic.
• • Total RJ45 Ports: 5 × 10/100/1000 BASE-T Gigabit ports
• • Port Breakdown:
• • 1 × Fixed WAN port
• • 1 × Fixed LAN port
• • 3 × LAN/WAN switchable ports (Supports up to 4 WAN ports for heavy load balancing)
• • PoE Capacity: None. It does not provide PoE power.
• • Hardware Upgrade: It features a larger 256 MB RAM (compared to 128 MB on the wired-only models).
• Performance & Capacities
• • Recommended Bandwidth: 600 Mbps
• • Concurrent Clients: Up to 150 total users (LAN + Wi-Fi combined)
• • Device Management: Can auto-discover and centrally manage up to 32 Reyee Access Points/NBS switches + 128 ES switches.
• Software Features
• • Mesh Network: Supports One-Click Reyee Mesh. You can press a physical button on the router to instantly link it wirelessly with other Reyee APs or routers.
• • Management: Free lifetime remote management via the Ruijie Cloud Web / Reyee Mobile App.
• • VPN Support: IPSec, OpenVPN, L2TP, and PPTP.
• Physical & Appearance
• • Design: It is a small white square box (120 mm × 120 mm × 28 mm). It looks more like an elegant smart home hub or a ceiling-mount access point. It does not have the long, metallic black/silver chassis of the wired-only EG105G series.
• • Power Supply: Powered by an external DC 12V/1.5A power adapter.
