Ruijie Reyee NIS-GE-SFP-20KM-SM1550-BIDI

Features

• Key Specifications
• • Data Rate: 1.25 Gbps (1000BASE-BX Gigabit Ethernet)
• • Fiber Type: Single-Mode Fiber (SMF) with a 9/125 µm core size
• • Connector Type: Simplex LC (Single port)
• • Target Reach: Up to 20 km (12.4 miles)
• • Optical Wavelengths: TX: 1550 nm (Transmit) / RX: 1310 nm (Receive)
• • Diagnostic Capabilities: Supports DDM / DOM (Digital Diagnostic Monitoring) for real-time temperature, voltage, and transceiver health monitoring.
• Transmitter & Receiver Optical Parameters
• • Minimum Transmit Power (TX Min.): –9 dBm
• • Maximum Transmit Power (TX Max.): –3 dBm
• • Minimum Receive Sensitivity (RX Min.): –22 dBm
• • Maximum Receive Sensitivity (RX Max.): –3 dBm
• Industrial Environmental Specifications
• • Operating Temperature: –40°C to 85°C (–40°F to 185°F)
• • Storage Temperature: –40°C to 85°C
• • Relative Humidity: 10% to 90% RH (non-condensing)
