Ruijie Reyee NIS-GE-SFP-10KM-SM1310

Features

• Key Specifications
• • Data Rate: 1.00 Gbps (1000BASE-LX Gigabit Ethernet)
• • Fiber Type: Single-Mode Fiber (SMF) with a 9/125 µm core size
• • Connector Type: Duplex LC
• • Target Reach: Up to 10 km (approx. 6.2 miles)
• • Optical Wavelength: 1310 nm
• • Diagnostic Capabilities: Supports DDM / DOM (Digital Diagnostic Monitoring for real-time temperature, voltage, and signal tracking).
• Transmitter & Receiver Optical Parameters
• • Minimum Transmit Power (TX Min.): –9.5 dBm
• • Maximum Transmit Power (TX Max.): –3 dBm
• • Minimum Receive Sensitivity (RX Min.): –20 dBm
• • Maximum Receive Sensitivity (RX Max.): –3 dBm
• Industrial Environmental Specifications
• • Operating Temperature: –40°C to 85°C (–40°F to 185°F) (Commercial models are typically limited to 0°C to 70°C)
• • Storage Temperature: –40°C to 85°C
• • Relative Humidity: 10% to 90% RH (non-condensing)
