Ruijie Reyee M6000-24SFP2XS

Specifications

• Warranty

5 years (synchronized with the host chassis warranty)

• Structure

Industrial-grade rigid metal frame

• Net Weight

Approximately 0.95 kg (2.09 lbs)

• Copper Ports

None (Pure optical interfaces)

• Product Type

Pure optical expansion line card / service module

• Power Consumption

≤ 44.4 W (The highest baseline draw among the M6000 line cards due to its multi-port transceiver architecture)

• Operating Humidity

10% to 90% RH (non-condensing)

• Software Management

Fully unified under the central chassis' ReyeeOS firmware (accessible through Ruijie Cloud or the local eWeb interface)

• Storage Temperature

-40°C to 70°C (-40°F to 158°F)

• Chassis Compatibility

Designed exclusively for the RG-NBS6002 modular switch series

• Operating Temperature

0°C to 50°C (32°F to 122°F)

• Dimensions (H × W × D)

40.3 mm × 227 mm × 210 mm (1.59 in × 8.94 in × 8.27 in)

• Fiber Distribution Ports

24 × 1Gbps independent SFP slots (LC-type connectors) for perimeter or edge network fiber aggregation

• SFP+ Ultra-High-Speed Uplinks

2 × 10Gbps independent SFP+ slots for central backbone connectivity, network-attached storage (NAS) clusters, or core routers

• MTBF (Mean Time Between Failures)

> 200,000 hours
