Ruijie Reyee M6000-16SFP8GT2XS
Specifications
- • Warranty
- 5 years (aligned with the main chassis warranty)
- • Net Weight
- 0.95 kg (2.09 lbs)
- • Copper Ports
- 8 × 10/100/1000BASE-T RJ45 Gigabit Ethernet ports with auto-negotiation
- • Product Type
- Mixed service / expansion line card
- • Compatibility
- Designed exclusively for the RG-NBS6002 modular chassis
- • SFP Fiber Ports
- 16 × 1Gbps SFP slots (LC-type connectors) for fiber-optic backhaul
- • Power Consumption
- ≤ 36.4 W
- • Operating Humidity
- 10% to 90% RH (non-condensing)
- • Software Management
- Unified under the chassis' ReyeeOS (via Ruijie Cloud or eWeb)
- • Storage Temperature
- -40°C to 70°C (-40°F to 158°F)
- • Operating Temperature
- 0°C to 50°C (32°F to 122°F)
- • Dimensions (H × W × D)
- 40.3 mm × 227 mm × 210 mm (1.59 in × 8.94 in × 8.27 in)
- • SFP+ Ultra-High-Speed Ports
- 2 × 10Gbps SFP+ slots for central backbone or core aggregation
- • MTBF (Mean Time Between Failures)
- > 200,000 hours
