Ruijie GE-SFP-LX20-SM1310-BIDI
Enterprise-grade, mid-range single-fiber bi-directional (BiDi) SFP optical transceiver module.
Features
- • Single-Strand Cabling Efficiency: Implements Wavelength Division Multiplexing (WDM) to transmit a 1310 nm signal and receive a 1550 nm signal over the same fiber core.
- • Complementary Pairing Requirement: Because this module sends at 1310 nm and listens at 1550 nm, it must be deployed opposite a matching GE-SFP-LX20-SM1550-BIDI module at the other end of the link to establish a functional circuit.
- • Digital Diagnostics Monitoring (DDM/DOM): Features built-in DOM capability, allowing administrators to gather real-time data regarding operating temperature, supply voltage, laser bias current, and transmitted/received optical power levels.
- • Industrial-Standard Safety: Built with a solid metal housing for excellent thermal dissipation and structural longevity. It is fully Class 1 Laser safety compliant and meets RoHS environmental standards.
Specifications
- • Data Rate
- 1.25 Gbps (Gigabit Ethernet)
- • Fiber Type
- Single-Mode Fiber (SMF)
- • Wavelength
- TX 1310 nm / RX 1550 nm
- • Form Factor
- SFP (mini-GBIC), hot-pluggable
- • Connector Type
- Simplex LC (Single LC/UPC)
- • Transmit Power
- -9 dBm to -3 dBm
- • Maximum Distance
- Up to 20 kilometers (20 km)
- • Ethernet Standard
- Aligned to 1000BASE-LX optical specifications
- • Power Consumption
- ≤ 1.5 W (Max)
- • Receiver Overload
- -3 dBm
- • Receiver Sensitivity
- < -20 dBm to -22 dBm
- • Optical Budget Parameters
