Ruijie 40G-QSFP-LX4-SM1310
Features
- • Dual-Media Flexibility: Works across both multimode (OM3/OM4) and single-mode fiber infrastructure, reducing spare part requirements.
- • Hot-Pluggable: Can be installed or removed from a live switch or router port without powering down the device.
- • Digital Diagnostics (DOM/DDM): Built-in monitoring allows real-time tracking of parameters like optical power levels and temperature.
- • Low Power Consumption: Operates efficiently with low thermal output, suitable for high-density switch and data center environments.
Specifications
- • Data Rate
- 40 Gbps aggregate bit rate
- • Wavelength
- 1264 nm – 1337 nm (1310 nm class)
- • Form Factor
- QSFP+
- • Connector Type
- Dual LC-LC
- • Max Reach (MMF)
- Up to 150 meters on OM3 / OM4
- • Max Reach (SMF)
- Up to 2 kilometers on single-mode fiber
- • Standards Compliance
- IEEE 802.3ba, QSFP+ MSA
