Ruijie 40G-QSFP-LR4-SM1310
Features
- • Long-Distance Backbone Links: Engineered to handle bandwidth-heavy enterprise core routing, backhaul distribution, and campus network interconnections.
- • CWDM Technology Multiplexing: Internally converts 4 separate channels of 10G electrical data into 4 lanes of CWDM optical signals, multiplexing them into a single optical fiber stream via the LC port.
- • Hot-Swappable Design: Allows immediate plug-and-play installation or replacement in active switches or data center routers without bringing down the hardware stack.
- • Compliance Standards: Aligned fully to industry-wide IEEE 802.3ba 40GBASE-LR4 specifications and standard QSFP+ Multi-Source Agreements (MSA).
Specifications
- • Data Rate
- 40 Gbps aggregate throughput (4 lanes x 10.3125 Gbps)
- • Model Name
- Ruijie 40G-QSFP-LR4-SM1310
- • Wavelength
- 1310 nm (utilizes 4 CWDM grid channels across 1270nm to 1330nm)
- • Diagnostics
- Digital Diagnostic Monitoring (DDM/DOM) capable
- • Form Factor
- QSFP+ (Quad Small Form-factor Pluggable Plus)
- • Connector Type
- Duplex LC interface
- • Max Link Distance
- 10 km over standard single-mode optical fiber
- • Operating Temperature
- 0°C to 70°C (Commercial Grade)
